Universal Pipe Coupling
Application Universal coupling is used for connecting pipes from various materials Design features Large tolerance The bolt ends are protected with plastic caps Technical Characteristics Maximum working pressure: PN16 / 16 bar Working temperature: 0°C – +70°C Color RAL5015 Powder epoxy coating 250 μm thickness Bolts, buts and washers – carbon steel 8.8 hot dip galvanized Maximum angular deflection – 4° Dimensions DN O.D Range D Bolts Bolt Qty. Weight Stock 50 57-... -
Universal Flange Adaptor
Application Universal flange adaptor is used for connecting various pipe materials with flanged fittings Design features Large tolerance Universal drilling for compatibility with both PN10 and PN16 The bolt ends are protected with plastic caps Technical Characteristics Flange end connections according to EN1092-2: PN10/PN16 Maximum working pressure: PN16 / 16 bar Working temperature: 0°C – +70°C Color RAL5015 Powder epoxy coating 250 μm thickness Bolts, buts and washers – carbon ... -
Dismantling Joint
Technical Characteristics Flange end connections according to EN1092-2: PN10/PN16 Designed according to EN545 Maximum working pressure: PN16 / 16 bar Working temperature: 0°C – +70°C Color RAL5015 Powder epoxy coating 250 μm thickness Body from ductile iron EN-GJS-500-7 Bolts, nuts and washers – hot dip galvanized 8.8 carbon steel Gasket – EPDM or NBR Dimensions DN Flange drill. D L1min L1max Bolts Qnty & Hole Size Weight 50 PN10/16 165 170 220 M16 4×19 9... -
Coupling for PE/PVC pipes
Application Restrained couplings dedicated for PE and PVC pipes Design features Restrained connection with brass ring prevents axial movement of the pipe Technical Characteristics Maximum working pressure: PN16 / 16 bar Working temperature: 0°C – +70°C Color RAL5015 Powder epoxy coating 250 μm thickness Bolts, nuts and washers: A2 stainless steel Locking ring- Brass Sealing gasket- EPDM Body- ductile iron EN-GJS-500-7 Dimensions DE L D L1 KG 63 171 124 80 2.6 75 175 138 8... -
Flange Adaptor for PE/PVC Pipes
Application Flange adaptors dedicated for PE and PVC pipes Design features Restrained connection with brass ring prevents axial movement of the pipe Technical Characteristics Flange end connections according to EN1092-2: PN10&PN16 Maximum working pressure: PN16 / 16 bar Working temperature: 0°C – +70°C Color RAL5015 Powder epoxy coating 250 μm thickness Bolts, nuts and washers – A2 stainless steel Sealing gasket EPDM Locking ring- brass Dimensions DN Flange drill. DE ... -
RTD-A Multifunctional Pipeline Connector
Name: RTD-A Multifunctional Pipeline Connector
Size: DN25-500
Material: : stainless steel
Shell: Stainless steel AISI304/AISI316L/AISI316Ti
Seal ring :EPDM,NBR
Additionally; optional H NBR MVQ,VITON A
Fastening :Anti-corrosion Dacromet treatment of heavy-duty
bolts, pins stainless steel,PTFE accessories can also be selected
Package:wooden crate -
RTD-B Tooth ring pipeline connector
Name: RTD-B Tooth ring pipeline connector
Size: DN25-500
Material: stainless steel
Limit toothed ring: Stainless steel AISI304/AISI316L/AISI316T
Shell:Stainless steel AISI304/AISI316L/AISI316Ti
Seal ring :EPDM,NBR
Additionally:optional H NBR MVQ,VITON A
Fastening :Anti-corrosion Dacromet treatment of heavy-duty
bolts, pins stainless steel,PTFE accessories can also be selected -
RTD-G Double card three-way pipeline repair clamp
Name:RTD-G Double card three-way pipeline repair clamp
Material: stainless steel -
RTD-E Single plate-type pipeline repair clamp
Name:RTD-E Single plate-type pipeline repair clamp
Diameter range: 59-118
Material: stainless steel
Shell: Stainless steel AISI304,AISI316L,AISI316Ti,
Seal ring:EPDM,NBR
Additionally; optional H NBR MVQ,VITON A
Fastening :Anti-corrosion Dacromet treatment of heavy-duty
bolts, pins stainless steel,PTFE accessories can also be selected -
RTD-F Double plate-type pipeline repair clamp
Name:RTD-F Double plate-type pipeline repair clamp
Diameter range: 59-118
Material: stainless steel
Shell: Stainless steel AISI304,AISI316L,AISI316Ti,
Seal ring:EPDM,NBR
Additionally; optional H NBR MVQ,VITON A
Fastening :Anti-corrosion Dacromet treatment of heavy-duty
bolts, pins stainless steel,PTFE accessories can also be selected -
RTD-D Double-clip pipeline repair clamp
Name:RTD-D Double-clip pipeline repair clamp
Size: DN25-500
Material: stainless steel
Shell: Stainless steelAISI304,AISI316L,AISI316Ti,
Seal ring:EPDM,NBR
Additionally; optional H NBR MVQ,VITON A
Fastening :Anti-corrosion Dacromet treatment of heavy-duty
bolts, pins stainless steel,PTFE accessories can also be selected -
RTD-C Single-clip pipeline repair clamp
Name: RTD-C Single-clip pipeline repair clamp
Size: DN25-500
Material: stainless steel
Shell: Stainless steel AISI304/AISI316U/AISI316T
Seal ring:EPDM,NBR
Additionally; optional H NBR MVQ,VITON A
Fastening :Anti-corrosion Dacromet treatment of heavy-duty
bolts, pins stainless steel,PTFE accessories can also be selected
