Flanged Tyton Socket
Application TYTON fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN E L Kg 80 7 130 7.4 100 7.2 130 9 125 7.5 135 11.5 150 7.8 135 14.2 200 8.4 140 ... -
Double Socket Tyton tee with Flanged branch
Application TYTON fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN dn L H KG 80 80 170 165 13.5 100 80 170 175 15.8 100 100 190 180 17.2 125 80 170 1... -
Tyton all socket T
Application TYTON fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN dn L H KG 80 80 170 85 12.4 100 80 170 95 14.8 100 100 190 95 16.1 125 125 225 110... -
Tyton bend 11.25°
Application TYTON fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN L E Kg 80 30 7 7.1 100 30 7.2 8.9 125 35 7.5 11.9 150 35 7.8 14.8 200 40 8.4 22 ... -
Tyton bend 22.5°
Application TYTON fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN L E Kg 80 40 7 7.3 100 40 7.2 9.3 125 50 7.5 12.6 150 55 7.8 15.9 200 65 8.4 24 ... -
Tyton bend 45°
Application TYTON fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN L E Kg 80 55 7 7.7 100 65 7.2 10.1 125 75 7.5 13.6 150 85 7.8 17.4 200 110 8.4 2... -
Tyton bend 90°
Application TYTON fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN L E Kg 80 100 7 8.6 100 120 7.2 11.4 125 145 7.5 15.7 150 170 7.8 20.5 200 220 8... -
PVC Double socket Tee with Flanged branch
Application PVC fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Maximum working pressure: PN16 / 16 bar Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN dn L H X KG 63 50 70 140 239 5.89 63 65 80 140 2... -
PVC Double Socket 90° Bend
Application PVC fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Maximum working pressure: PN16 / 16 bar Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions OD L R KG 50 60 52 2.27 63 65 57 3.08 75 70 62 3.... -
PVC Double Socket 45° Bend
Application PVC fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Maximum working pressure: PN16 / 16 bar Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socketgaskets made from EPDM/NBR rubber Dimensions DN L R KG 50 40 78 2.10 63 40 78 2.79 75 40 78 3.5... -
PVC Double Socket 22.5° Bend
Application PVC fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Maximum working pressure: PN16 / 16 bar Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN L R KG 50 20 60 1.82 63 20 60 2.43 75 25 85 3.... -
PVC Double Socket 11.25° Bend
Application PVC fittings for drinking water and neutral liquids up to +70°C Technical characteristcs Body – Ductile cast iron EN-GJS-500-7 According to DIN EN 545/598/BS4772/ISO2531 standards Maximum working pressure PN16 Working temperature: 0˚C- +70˚C Maximum working pressure: PN16 / 16 bar Epoxy coating RAL5015 250 μm thickness or other coating based on request Push-on socket gaskets made from EPDM/NBR rubber Dimensions DN L R KG 50 20 112 1.82 63 20 112 2.43 75 25 172...
